SPX™ Side Discharge Tractors

Featuring powerful Briggs & Stratton engines, the SPX range provides superior cutting and handling under a variety of mowing conditions. Tough gauge wheels are fitted on all four corners of the mowing deck offering additional protection. The durable pivoting cast iron front axle provides the SPX tractor with an excellent turning radius of 36 cm, which will make short work of manoeuvering around complex gardens.

Choose between the 107 or 117 cm stamped steel decks suitable for most gardens. Should you require an even more rugged mower deck, the SPX300 offers a 122 cm fabricated steel deck. The SPX is stylish and offers an enhanced mowing experience for gardeners with larger lawns.

FIND A DEALER
snapper /

Product Details

Ergonomically designed dash board

Comfortable seat

The seat is adjustable in 9 positions.

LED headlights

These powerful LED headlights light the path. (Standard bulbs on the SPX100).

Rigid steel moving decks

Choose between 107, 117 or 122 cm cutting width.

7 position height-of-cut

Durable pivoting cast-iron front axle

The cast-iron pivoting front axle smoothly tracks over rough terrain for an even cut.

Model Name SPX100
Engine Brand Briggs & Stratton
Engine Model Intek™ Series 4175 OHV, AVS®
Engine Displacement (cc) 500,0
Number of Cylinders 1,0
Starting Type Electric Start
Fuel Tank Capacity (l) 13,2
Drive Type Hydro-Gear® T2
Ground Speed - Fwd (km/h) 0 - 8,9
Ground Speed - Rev (km/h) 0 - 5,3
Frame Steel
Front Tyres (in) 15 x 6
Rear Tyres (in) 20 x 8
Turning Radius (cm) 36,0
Deck / Attachment Lift Manual / -
Cutting Width (cm) 107,0
Mower Deck Frame Hung
Height-of-Cut (mm) 45 - 85
Height-of-Cut Adjustment 7,0
Number of Blades 2,0
Mulching Kit Optional
Gauge Wheel Kit N/A
Length (cm) 177
Width (cm) 136
Height (cm) 112
Wheel Base (cm) 127,0
Weight (kg) 201
Residential Warranty * 3-Year Limited

* See operator's manual or dealer for complete warranty details. Length of engine warranty coverage varies by manufacturer.

Model Name SPX200
Engine Brand Briggs & Stratton
Engine Model Intek™ Series 7220 V-Twin OHV
Engine Displacement (cc) 656,0
Number of Cylinders 2,0
Starting Type Electric Start
Fuel Tank Capacity (l) 13,2
Drive Type Turf Torq® K46
Ground Speed - Fwd (km/h) 0 - 8,9
Ground Speed - Rev (km/h) 0 - 5,3
Frame Steel
Front Tyres (in) 15 x 6
Rear Tyres (in) 22 x 10
Turning Radius (cm) 36,0
Deck / Attachment Lift Manual / -
Cutting Width (cm) 117,0
Mower Deck Frame Hung
Height-of-Cut (mm) 38 - 92
Height-of-Cut Adjustment 7,0
Number of Blades 3,0
Mulching Kit Optional
Gauge Wheel Kit Included
Length (cm) 179
Width (cm) 150
Height (cm) 114
Wheel Base (cm) 127,0
Weight (kg) 228
Residential Warranty * 3-Year Limited

* See operator's manual or dealer for complete warranty details. Length of engine warranty coverage varies by manufacturer.

Model Name SPX300
Engine Brand Briggs & Stratton
Engine Model Professional Series™ 8230 V-Twin OHV
Engine Displacement (cc) 724,0
Number of Cylinders 2,0
Starting Type Electric Start
Fuel Tank Capacity (l) 13,2
Drive Type Tuff Torq® K46
Ground Speed - Fwd (km/h) 0 - 8,9
Ground Speed - Rev (km/h) 0 - 5,3
Frame Steel
Front Tyres (in) 15 x 6
Rear Tyres (in) 22 x 9,5
Turning Radius (cm) 36,0
Deck / Attachment Lift Manual / -
Cutting Width (cm) 122,0
Mower Deck Frame Hung - Fabricated
Height-of-Cut (mm) 38 - 92
Height-of-Cut Adjustment 7,0
Number of Blades 3,0
Mulching Kit Optional
Gauge Wheel Kit Included
Length (cm) 179
Width (cm) 150
Height (cm) 114
Wheel Base (cm) 127,0
Weight (kg) 233
Residential Warranty * 3-Year Limited

* See operator's manual or dealer for complete warranty details. Length of engine warranty coverage varies by manufacturer.

Mulching Kit

Coverts easily to a mulching deck. Available for SPX100 (1696374YP), SPX200 (1695946YP) and SPX300 (1696693YP).

Bag Collector

Twin Bag Collector for the SPX100 (1696073), Triple Bag Collector for SPX200 (1695776) and SPX300 (1696462). Triple Bag Collector requires Turbo Fan (SPX200: 1695642, SPX300: 1696750).

Turbo Fan

Available for SPX200 (1695642) and SPX300 (1696750).

Weight Carrier, Rear

Available for all SPX Side Discharge Tractor models (1694922SM). SPX200 and SPX300 require 33 lbs/15 kg weight (1691319SM).

Weight 33 lbs (15 kg)

Available for SPX100, SPX200 and SPX300 (1691319SM).

Wheel Weights (needs 2)

Only available for SPX200 (1690555SM).

Dozer Blade 42”

Dozer blade for SPX200 and SPX300 (1696092). Requires weight carrier (1694922SM), weights (1691319SM) and tyre chains (1695092SM).

Snowthrower 42”

Single stage snowthrower of 42"/107 cm for SPX200 and SPX300 (1696423). Requires weight carrier (1694922SM), weights (1691319SM) and tyre chains (1695092SM).

Tyre Chains

Chains for 22” x 10” tyres, available for SPX200 and SPX300 (1695092SM). For use on slippery surfaces.

NEW: Eliminator® Blades*

Superior cutting performance and more versatility. Available for SPX200 (1760646YP) and SPX300 (1760647YP).

* Eliminator® Blades are a registered trade mark of Fisher Barton.
