      ZTX105 Zero Turn Mower

      ZTX105 Zero Turn Mower
      ZTX105 Zero Turn Mower
      ZTX105 Zero Turn Mower
      ZTX105 Zero Turn Mower
      ZTX105 Zero Turn Mower
      ZTX105 Zero Turn Mower
      ZTX105 Zero Turn Mower
      ZTX105 Zero Turn Mower

      ZTX105 Zero Turn Mower

      The ZTX105 brings a whole new level of performance to the comprehensive Snapper® zero turn range. Designed for maximum garden access, this compact zero turn mower reaches places other zero turns cannot reach.

      The fabricated steel 91 cm mower deck is the smallest in class, making sure it delivers unparalleled garden access. Because of the small size of the mower, it is easy to navigate even through the tightest parts of your lawn and takes up less space when in storage. Without compromising on the quality and your comfort.

      Feature

      Features

      Foot-assisted mower deck lift

      No more heavy manual lifting of the mower deck. Easily adjust between different cutting heights.

      Compact zero turn mower

      Designed for unparalleled garden access, this compact zero turn mower reaches places other zero turns cannot reach.

      Comfortable seat

      Adjustable seat with arm rests for optimal ergonomics.

      Powered by Briggs & Stratton

      The Series 7 Professional Series™ engine delivers consistent and reliable power, ensuring superior performance and durability.

      7 Height-of-cut positions

      The commercial- styled foot operated mower deck ift easily lifts and adjusts the mower deck between 7 heights-of-cut positions from 38 mm to 114 mm.

      Steering lever tracking adjustment

      Two lever steering controls with tracking adjustment for a more convenient and comfortable operation.

      Fabricated steel mower deck

      The ZTX105 has a durable 36" / 91 cm fabricated steel mower deck that can whitstand even the roughest terrains. Including a washout port, providing easy cleaning of the mower deck by connecting a standard garden hose to the connector.

      Easy access to deck maintenance points

      Get easy access to the deck maintenance points with the removable floor plate.

      Specifications

      Only 2 products can be compared at once. Please remove one of your selections to compare this product.

      Only 3 products can be compared at once. Please remove one of your selections to compare this product.

      At least one product must be displayed. Please select another option to remove this product

      Model Number
      2691707
      Engine Brand
      Briggs & Stratton
      Engine Model
      7200 EXi V-Twin OHV
      Cylinders
      2
      Starting System
      Electric Start
      Fuel Capacity (l)
      11
      Drive Type
      Hydro Gear® EZT®
      Forward Speed (km/h)
      0 - 8,0
      Reverse Speed (km/h)
      0 - 4,0
      Frame
      Welded Steel
      Tyres Front (in)
      11 x 4
      Tyres Rear (in)
      18 x 6,5
      Turning Radius (cm)
      0
      Mower Deck Lift
      Foot operated
      Blade Engagement
      Electric
      Cutting Width (cm)
      91
      Mower Deck
      Frame Hung
      Deck Construction
      Fabricated Steel
      Deck Support Wheels
      -
      Discharge
      Side Discharge
      Height-of-Cut (mm)
      38 - 114
      Height-of-Cut Adjustment
      7
      Blades
      2
      Seat
      Mid-Back & armrests
      Cargo Bed*
      Optional
      Wash Port
      Yes
      Mulch Kit/Plug
      Optional
      Parking Brake
      Integrated
      Length (cm)
      178
      Width (cm)
      125
      Height (cm)
      107
      Wheel Base (cm)
      112
      Weight (kg)
      231
      Residential Warranty (Product)**
      3-Year Limited

      * 22,7 kg. capacity, do not overload; do not carry passengers. See operator’s manual for details.
      ** See operator's manual or dealer for complete warranty details. Length of engine warranty coverage varies by manufacturer.

      Accessories

      Mulch Kit

      Converts easily to a mulching deck.

      Part number: 1697102

      Collector

      Including front counter weight. Requires deck boot adapter.

      Part number: 1697100

      Deck Boot Adapter

      Part number: 1697101

      Cargo Bed*

      Provides on-the-go versatility and convenience for working in the yard.

      Part number: 1696711

      Cargo Bed Rhino Grips (2)

      Easily mount additional garden tools on your zero turn.

      Part number: 1687855YP

      Cargo Bed Rhino Grips with Ratchet (2)

      Increased cushioning and gripping power for items in a variety of shapes and sizes, from 1" (2,5 cm) to 4" (10 cm) diameter.

      Part number: 1687856YP

      Light Kit

      Two LED headlights for all round mowing.

      Part number: 1697104
